Datenblatt
Durchflussdiagramme,
DN 20(continuous)
© Danfoss | 2020.06
Strangregulierventil LENO™ MSV-B
Einstellung
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0.10
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
Durchflusscharakteristik
K
v
7
6
5
4
3
2
1
0
0
kV-Wert
0.13
0.15
0.19
0.24
0.30
0.37
0.45
0.53
0.61
0.68
0.76
0.84
0.92
0.99
1.06
1.13
1.21
1.28
1.35
1.43
1.50
1.59
1.67
1.76
1.86
1.96
2.07
2.19
2.31
-value
1 . 0
2 . 0
3 . 0
4 . 0
Setting
Einstellung
kV-Wert
2.9
2.44
3.0
2.58
3.1
2.72
3.2
2.87
3.3
3.03
3.4
3.19
3.5
3.36
3.6
3.53
3.7
3.70
3.8
3.87
3.9
4.05
4.0
4.23
4.1
4.40
4.2
4.58
4.3
4.75
4.4
4.91
4.5
5.07
4.6
5.22
4.7
5.37
4.8
5.51
4.9
5.64
5.0
5.77
5.1
5.88
5.2
5.99
5.3
6.09
5.4
6.19
5.5
6.29
5.6
6.39
5.7
6.49
5.8
6.60
5 . 0
6 . 0
AI100486471298de-000401 | 15
