3. Connection of power supply

The unit is delivered complete with cable and plug for connection to 230V / 50Hz.
Power is connected to the unit in accordance with the nameplate. Please refer to the wiring diagram on page 33.

4. Operation

4.1 LED indication / Switch

The LED on the front of the unit is green when the compressor is operating, and the unit dehumidifies.
The dehumidifier is switched on and off by the switch on the side.
NOTE! Any stop of the unit – either caused by failing power connection, by the

4.2 Built-in hygrostat

The dehumidifier is controlled by a built-in hygrostat that is set to approx. 50% RH. When the hygrostat registers a
relative humidity of more than 50%RH, the compressor and the fan automatically switch on and the dehumidifier
starts to dehumidify.
The front panel has to be removed before adjusting the hygrostat. The hygrostat is located under the control box
and can be adjusted by turning the set screw.
If you want to set the hygrostat at a lower relative humidity than 50% the set screw has to be turned clockwise.
NOTE! All electrical connections must be made in
accordance with local power supply
company regulations.
switch on the side of the unit, by the hygrostat, or by the water tank's water
stop function - will make the electronic control put off re-start for 45
seconds in order to protect the compressor from being switched on and off
repeatedly.
NOTE! If the air humidity is below 50%RH, the unit will not
start when the power is connected.
12
