Partlist
Part No.
1 Main frame
2 Rear stabilizer
3 Front stabilizer
4 Foot Cap triangle
5 Handlebar post
6 Slip track (plate)
7 Spring washer (chromium)
8 Inner hex bolt
9 Inner hex bolt (chromium)
10 Nylon nut (chromium)
11 Curved washer (chromium)
12L Rear chain cover (left)
12R Rear chain cover (right)
13 Flat washer
14 Inner hex bolt
15L Crank (left)
15R Crank (right)
16L\R Pedal set
17 Inner hex bolt (chromium)
18 Crank axle
19 C-clip (black)
20 Hex bolt (chromium)
21 Nylon nut (chromium)
22 Hex bolt (nylock)
23 Screw cap(black)
24 Ball bearing
25 Belt
26 Flywheel (single-direction)
27 Flat washer (zinc)
28 Anti-loosing nut
29 Flat washer (zinc)
30 Endcap
31 Idle wheel fixing plate (zinc)
32 Spring (zinc)
33 Idle wheel
34 Nylon nut
35 Spacer
36 Nylon (zinc)
37L Front chain cover (left)
37R Front chain cover (right)
38 Backrest cushion
39 Adapter
40 Wireness chest
41 Adjustable rod (zinc)
42 Seat cushion
43 Transportable wheel
44 Littler crisscross screw (zinc)
Description Specification
160*110*88
50*100*2.0T+740L
D15.4xD8.2x2T
M8*1.25*40
M8*1.25*20L
M8*1.25*8T
D22*D8.5*1.5T
D16xD8.5x1.2T
M8x1.25x15L
6 1/2"x9/16"-20UNF
6 1/2"x9/16"-20UNF
JD-22A 9/16"thread
M8*1.25*70
S-16 (1T)
M6x1.0x15L, 8.8 class
M6x1.0x6T
M8x1.25x25
D23x6.5
#6003ZZ
450 PJ6
D274*125L (Al)
D22*D10*2T
3/8"-26UNFx6.5T
D25*D8.5*2.0T
D25.4*31L
D2.6*105.5L
M10x1.5x10T
D22.5xD17.2x6.4T
M8*1.25*8T
410*340*57
Out put 24V
D12*122*152
348*270*52
D48*D5*21
M5*0.8*35
5
Q'ty
1
1
1
4
1
1
8
4
4
12
4
1
1
18
15
1
1
1
4
1
3
4
4
2
2
2
1
1
4
4
1
2
1
1
1
1
1
1
1
1
1
1
1
1
2
2
