STRING
↵
DSTOP
↵
H
↵
DSTAR
Figure 2 : Strings of Request/Command to a Single Station
STRING
↵
00Z
↵
00DMAX
↵
00DMIN
↵
00DDIFF
00DMEAN
00DSEMI
00DCYCL
00DSTOP
↵
00H
00DSTAR
00QRBIN
Figure 3 : Strings of Request/Command to All Stations
192
Stop for Any Dynamic Measure Cycle to a Selected
QuickRead
Start/Stop for Hold Cycle to a Selected QuickRead
Select Dynamic Type Measure or Start/Stop for Hold Cycle
from Local Parameter Programmable MeasType to a Selected
QuickRead
Zeroing Request to All QuickRead Units
Select Dynamic Type Measure of Maximum to All QuickRead
Units
Select Dynamic Type Measure of Minimum to All QuickRead
Units
Select Dynamic Type Measure of Maximum – Minimum to All
QuickRead Units
Select Dynamic Type Measure of (Maximum + Minimum)/2 to
↵
All QuickRead Units
Select Dynamic Type Measure of (Maximum – Minimum)/2 to
↵
All QuickRead Units
Start/Stop for Dynamic Cycle of Selected Measure to All
↵
QuickRead Units
↵
Stop for Any Dynamic Measure Cycle to All QuickRead Units
Start/Stop for Hold Cycle to All QuickRead Units
Select Dynamic Type Measure or Start/Stop for Hold Cycle
↵
from Local Parameter Programmable MeasType to All
QuickRead Units
↵
Request of Passing to QrBin Protocol to All QuickRead Units
SHORT DESCRIPTION
SHORT DESCRIPTION
