Operating and installation instruction for PY X-L-15/ PY X-LA-15 beacon
Dimensions
PY X-L-15
Content of package:
1x Alarm device
1x Diaphragm nipple M20
1x Operating instruction
1x Resistor (only -SSM)
PY X-LA-15

Technical Data

Flash energy
Rated effective luminous
intensity
Flash frequency
Nom. sound level
Volume control
Tones
Rated voltage
(see special
requirements for approved
units on page 6)
Frequency
Operating voltage range
Current consumption max.
Beacon (1Hz) [mA]
Current consumption nom.
Beacon (1Hz) [mA]
Current consumption
Sounder [mA]
Power consumption
Duty cycle
Connection terminal
Protection system
Resistance against impact
Protection class
Operating temp.
Storage temperature
Max. rel. Humidity
Cable entry
Sealing range of
diaphragm nipple
Material of housing
Material of lens
Installation position
Option
Lens colours
085 501 995a
Prepared M20 piercing (both sides)
PY X-L-15
15J
190 cd (clear)
-
-
-
230V AC 115V AC
50/60 Hz
187 – 255 90 – 135 21.6 – 26.4
V AC V AC
170 350
150 300
- -
34,5 VA 34,5 VA
4x M20 (prepared)
7 – 13 mm
- Control input, -SSM (Soft start module, 24V DC only)
0,1 / 0,5 / 0,75 / 1 Hz
24V AC 24V DC
230V AC
(+/-10%) (+/- 20%)
-
187– 255V
19.2 – 28.8V
V AC
670
970
890 540
- -
13 W
22 VA
100%
0,14 - 2,5mm² / AWG24 - AWG 14 (stranded)
IP66 (EN60529) , Type 4 & 4x
IK 08 (EN50102)
II Double insulated equipment
-40°C...+55°C (UL certification see page 6)
-40°C...+70°C
90%
- With the use of cable diameters <7 mm, a cable screw joint
with sufficient ingress protection must be provided
PC/ABS Blend
PC
arbitrary
clear, white, yellow, amber, red, green, blue
5
Prepared M20
Piercing
PY X-LA-15
15J
190 cd (clear)
102 dB (A) @1m
max. - 20 dB
8
24V AC
115V AC
(+/-10%)
50/60 Hz
90 – 135 21.6 – 26.4
V AC
V AC V AC
170 350 970
150 300 890
50 Hz: 60 Hz:
50/60Hz: 40
10 – 25 10 – 20
38 VA 36,5 VA 23 VA
4x M20 (prepared)
24V DC
(+/- 20%)
-
19.2 – 28.8V
670
540
20
13,5 W
