MAINTENANCE AND STORAGE

6.
- During maintenance operations, use the individual
protections indicated by the Manufacturer , especially
when intervening on the blade.
- Before performing maintenance operations, make
sure that the robot has stopped in safety conditions.
PROGRAMMEDMAINTENANCEINTERVALSCHART
Frequency Component
Blade
Every week
Every month Robot
Every 3 months Robot
Robot cleaning
6.1
1. Stop the robot in safety conditions.
2. Wear protective gloves.
3. Clean all the outside surfaces of the
robot with a sponge soaked in warm water.
4. Do not use solvents or benzene so not to damage
the varnished surfaces and the plasticcomponents.
5.Do not wash the inside parts
of the robot and do not use water
jets in pressure so not to damage
the electric and the electronic
components.
WARNING
Never use a high-pressure washer or
even running water to clean the robot.
6. Check the lower part of the robot (cutting blade area and
wheels) and remove the deposits and/or residues that
might obstruct the correct functioning of the robot.
7.
To remove the deposits and/or other residues from
the blade, use a suitable brush.
8. Clean the outside of the charging station
9.
Keep all nuts, bolts and screws tight to be sure the
appliance is in safe working condition.
10.
Replace worn or damaged parts for safety.
11.
Ensure that only replacement cutting means of the
right type are used.
12.
Ensure that batteries are charged by using the correct
charger recommended by the manufacturer.
13.
Incorrect use may result in electric shock,
overheating or leakage of corrosive liquid from the
battery.
14.
In the event leakage of electrolyte flush with
water/neutralising agent, seek medical help if it
comesinto contact with the eyes etc.
6. MAINTENANCE AND STORAGE
Type ofoperation Reference
See "Robot
Clean and check the
cleaning"
efficiency of the
blade
If the blade is bentdue See "Blade
to an impact or if it is
replacement
worn-out, replaceit. "
See "Robot
Carry outcleaning
cleaning"
See "Battery"
Carry out for rechage
15.
Servicing of the mower should be according to
manufacturers instructions. This product
(include battery pack)must be disposed of at a
designated collection pint for electrical and electronic
waste. For more information, contact
your local city office or the shop where you
purchased the product.
Robot Storage
6.2
Packed the mower and all spareparts with the original
package, and storage the carton off the ground in a
cool, dry place. Temperature should not be colder
than 14F°(-10℃)

Blade replacement

6.3
Blade replace steps:
1. Stop the robot in safe conditions.
2. Wear protective gloves.
3. Turn the Robot upside down.
4. Unscrew the blade and remove it.
5. Replace a new blade and screw it tightly.
Front wheel cleaning
6.4
When front wheels are not easy to rotate, please turn robot
upside down, check it and dismantle the screw cap to take
the front wheel out of robot, dismantle end caps and remove
the residues, like mud, grass etc from end cap,
then reinstall it on the robot.
Battery
6.5
The battery is maintenance-free, but has a limited life
span of 1-3years. Battery life is dependent on the
length of the using season and how many hours per
week the robot is used. A long season or many hours of
use per week, means that the battery must be replaced
more regularly.
- Attentions of lithium batteries
Please charge the lithium batteries in accordance with
standard time and procedures.
When the power is too low. It should be started
charging as soon as possible.
Storage, we suggest the optimum storage of lithium
battery is with 80% power and keep in the shade.
Don't connect the anode and cathode of battery.
Don't take apart, repair or modify the battery privately.
- Disused battery processing
Please contact the nearest waste treatment center and
consultation with recycling and proper disposal
of views.
IMPORTANT INFORMATION
Charge the battery fully at the end of the season
before winter storage. And recharge it every 3
- 17 -
months.
