IMPORTANT INFORMATION
If user does not select working in AREA 2, he can not
set the robot working in AREA 3.
- Press key or key
toselectworkinginAREA3."*"comesinfrontofAREA3.
4. To set the Memory Point.
A Memory point is to program the mower where to leave
virtual wire and go inner lawn.Each area should have a
Memory point.
Please keep the voltage of mower more than 27V
before setting the memory points.
- Put the mower at the charging station
- Select START and confirm it by pressing key
the robot starts follow virtual wire walking.
- Press key to set Memory point in AREA 1 when mower
arrives at Memory 1.
Press key to set Memory point in AREA 2 when mower
arrives at Memory 2.
Press key to set Memory point in AREA 3 when mower
arrives at Memory 3.
Take Memory 1, Memory 2, Memory 3 as below picture
for example.
- It's best to set the Memory point in the middle of two
corners.
- A better position of Memory point is a 3 meters length
of virtual wire at the beginning or the end of an area.
- Route the wire around the passage to separate the area.
The virtual wire to and from the edge of passage is 1meter
at least. check the setting as below picture.
- Aminimumdistance between the toand from virtualwire which
are to make a passage from one area to another one is 50cm.
- Put the robot back to charging station and wait for
to scroll to AREA 3 and press key
.
. Then
5. USE
Schedule time setting
5.13
The schedule time setting should be used together
with AREA
1. Select AREA
2. Select SCHEDULE TIME and enter it by pressing key
3. Select WEEK (
SUN)
and enter it by pressing key
4. To set START TIME.
Select START TIME and enter it by pressing key
-
- Press key
and confirm the settings by pressing key
5. To set working time in each area.
Select AREA 1 and enter it by pressing key
-
- Press key
works in AREA 1,and confirm the settings by pressing key
.10minutes for each scrolling.(From 000 to 500minutes).
6. Set AREA 2 to AREA 6 as Step5.
Explanation:
- If Set AREA 1 with 000 minute, it means Non-cutting in
AREA 1.
- If user doesn't select working in AREA 2. (See
5.12AREA SETTING
time in AREA 3, robot will not work in AREA 3.
7. Select EXIT to save or select DEL to delete the settings.
LINE
5.14
LINE:every time mower starts,it has to find wire
cutting and follow it back to station first.
1. Select AREA
2. Select LINE and enter it by pressing key
3. Select which day and confirm the selection by
pressing key
IMPORTANT INFORMATION
All settings need about 3 seconds to memorize, so pls
do not turn off the mower immediately after setting.
working.
- 16 -
function. P15-5.12 AREA setting.
and enter it by pressing key
MON,TUE,WED,THU,FRI,SAT,
or key to set Hour/ Minute.
or key to set how long should the robot
). Even user has set a working
and enter it by pressing key
.
.
.
.
.
.
.
P15-
.
.
