4. CONTROL PANEL

Control Panel view
5
3
Display
1
A. Charging station symbol
.
B
Working schedule symbol
.
C Rain sensor symbol
D.
Line symbol
E. Auto mode
F.Battery voltage
G.
Month / Date
H . Week
I . Hour / Minute
J .Touch sensor
A B C D J
H
Up / + :
2
-select menu, go upward
-select menu, go left
-Select figure, means +
Enter button
3
-To confirm your selection or enter it.
Down / -
4
-select menu, go down
-select menu, go right
- Select figure, means -
5 Home button
Press this button when the mower is operating, it goes
home for recharge automatically.
4. CONTROL PANEL
1
Function setting
Area setting
Inquiry
E F
I J
2
4
