Appendix A. Installation Drawings ACT20X-HDI-SDO (NAMUR Pulse Isolator)
Terminal (51, 52)
Supply
Voltage
Power max.
Terminal (53, 54)
Status Relay
Voltage max.
Current max.
Power max.
Terminal CH1 (41, 42) and CH2 (43, 44)
Digital Output, NPN Output
Voltage max.
Current max.
Terminal CH1 (41, 42) and CH2 (43, 44)
Relay Output
Voltage max.
Current max.
Power max.
86
19.2...31.2 V DC
3 W
Non Hazardous
Location
125 V AC / 110 V DC
0.5 A AC / 0.3 A DC
62.5 VA / 32 W
30 V DC
80 mA
Non Hazardous
Location
250 V AC / 30 V DC
2 A AC / 2 A DC
500 VA / 60 W
Zone 2 Installation
32 V AC / 32 V DC
0.5 A AC / 1 A DC
16 VA / 32 W
Zone 2 Installation
32 V AC / 30 V DC
2 A AC / 2 A DC
64 VA / 60 W
