Illustration 7-54:
FM Installation Drawing (2), (453449 Sheet 9-13)
Terminal CH1 (11, 12), CH2 (21, 22)
Ex Input (External Current Source)
U
, V
o
OC
I
, I
o
SC
P
o
U
, V
i
max
I
, I
i
max
P
i
C
i
L
i
1066530000/08/12-2018
Appendix E. Installation Drawings ACT20X-HAI-SAO (HART-transparent Repeater)
0 V
0 mA
0 mW
30 V
120 mA
0.85 W
2 nF
0 µH
181
