Weidmuller ACT20X Handbuch Seite 173

Illustration 7-51: IECEx Installation Drawing (3), (453449 Sheet 5-8)
Terminal CH1 (14), CH2 (22)
Ex Input (Loop Current Source Channel 1 to Channel 2)
U
o
I
o
P
o
Group
IIC
IIB
IIA
I
1066530000/08/12-2018
Appendix E. Installation Drawings ACT20X-HAI-SAO (HART-transparent Repeater)
28 V
93 mA
0.65 W
C
o
0.08 µF
0.6 µF
2.15 µF
3.76 µF
L
o
3 mH
12 mH
25 mH
30 mH
173
