Weidmuller ACT20X Handbuch Seite 184

Appendix E. Installation Drawings ACT20X-HAI-SAO (HART-transparent Repeater)
Terminal (41, 42, 43, 44) and (51, 52, 53, 54)
Supply / Output
U
m
Terminal (51, 52)
Supply
Voltage
Terminal (53, 54)
Status Relay
Voltage max.
Current max.
Power max.
184
253 V, max. 400 Hz
19.2...31.2 V DC
Non Hazardous
Location
125 V AC / 110 V DC
0.5 A AC / 0.3 A DC
62.5 VA / 32 W
Zone 2 Installation
32 V AC / 32 V DC
0.5 A AC / 1 A DC
16 VA / 32 W
1066530000/08/12-2018
