3. Layout, Connections & LED's
3.1 Layout & LED's
Front:
Reset Status LED
Back:
LEDs:
LED Name
Power/Act LED
(RJ45)
PoE LED
(RJ45)
Status LED
TXD LED
(right)
RXD LED
(left)
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
RXD LED 2x Serial 9 Pin D-SUB Connector
PoE LED
RJ45 Port
Color
Steady on: Ethernet is connected
Green Blinking: Transferring data on the Network
Off: Ethernet is not connected
Orange No function
Blinking: The unit has booted
Green
Off: The unit is not booted yet
Blinking: The Serial Port is sending out data
Green
Off: The Serial Port is not sending out any data
Blinking: The Serial Port is receiving data
Green
Off: The Serial Port is not receiving any data
Power/ACT LED
5-24V T-Block
for optional
Power Supply
LED Function
(25 ~ 30 seconds required from power up)
19
English
TXD LED
5-24V DC Connector for
included Power Supply
