3. Layout, Connections & LED's

3.1 Layout

12-48V DC Socket for
supplied power supply
TX/RX
Run
Power
3.2 LED's
LEDs:
LED Name
Activity LED
(RJ45)
LAN LED
(RJ45)
Power LED
RUN LED
TX/RX LED
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
12-48V T-Block for
optional power supply
LAN / Activity
Ethernet Port
Color
Steady on: Network is connected
Yellow
Blinking: Transferring data on the Network
Off: No connection
Steady on: Network ist connected
Green
Off: No connection
Steady on: Device is powered
Red
Off: No power connected
Steady on: Device is booting
Green
Blinking: Server is ready for end devices
Off: Server is not ready
Blinking: Serial port data transmission
Green
Off: No data transmission on the serial port
RS-232
LED Function
17
English
RS-422/485
Reset
