3. Layout, Connections & LED's

3.1 Layout

12-48V DC Socket for
supplied power supply
Run
Power
3.2 LED's
LEDs:
LED Name
Activity LED
(RJ45)
LAN LED
(RJ45)
Power LED
RUN LED
T/R1 & T/R2
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
12-48V T-Block for
optional power
LAN / Activity
Ethernet Port
Color
Steady on: Network is connected
Yellow
Blinking: Transferring data on the Network
Off: No connection
Steady on: Network ist connected
Green
Off: No connection
Steady on: Device is powered
Red
Off: No power connected
Steady on: Device is booting
Green
Blinking: Server is ready for end devices
Off: Server is not ready
Blinking: Serial port data transmission
Green
Off: No data transmission on the serial port
1
2x serial RJ45
(DB9 via cable-adapter)
LED Function
18
EX-61002
2
Reset
