Product description
3.1.2 Rotor bearing
Hybrid-bearing turbopump
● High vacuum side: wear-free permanent magnetic bearing
● Fore-vacuum side: ball bearing with ceramic balls
Permanent lubrication of the rotor bearing on the fore-vacuum side is ensured by an operating fluid res-
ervoir.
3.1.3 Drive
● TC 110 electronic drive unit
3.2 Identifying the product
► To ensure clear identification of the product when communicating with Pfeiffer Vacuum, always
► Learn about certifications through test seals on the product or at
3.2.1 Product types
The product designation of Pfeiffer Vacuum turbopumps from the HiPace series is composed of the
family name, the size (which is based on the pumping speed of the vacuum pump) and, if required, an
additional feature description.
Family
HiPace
Tbl. 3:
3.2.2 Product features
Feature
HV flange
Flange material
Tbl. 4:
3.3 Scope of delivery
● Turbopump with electronic drive unit
● Protective cover for the high vacuum connection
● Protective cover for the fore-vacuum connection
● Operating instructions
74/112
keep all of the information on the rating plate to hand.
ny ID no. 000021320.
Size/model
10 to 2800
Product designation of Pfeiffer Vacuum HiPace turbopumps
DN 63 ISO-K
Aluminium
Turbopump features
Property, attribute, feature
none = Standard version
mini = Compact version
U = Overhead version
C = Corrosive gas version
P = Process
M = Active magnetic bearing
T = Temperature management
Plus = Low vibration, low magnetic field
E = High efficiency
H = High compression
I = Ion implantation
Version
DN 63 CF-F
Stainless steel
www.certipedia.com with compa-
DN 40 ISO-KF
Aluminium
