Technical data

Note!
The following values apply for all standard separators:
• Max. temperature: 0-110 °C
• Max. pressure: 10 bar
• Special versions according to individual specification and nameplate.
Contact the manufacturer to determine the weight of the separator.
3.1 Exdirt V
D 50 V 16
D 65 V 18
D 80 V 22
D 100 V 24
D 125 V 38
D 150 V 44
3.2 Exvoid V
D 50 V 16
D 65 V 18
D 80 V 22
D 100 V 24
D 125 V 38
D 150 V 44
K L
VS
(m /h) (m /h) (mm)
3 3
64.5 12.5 230
109.5 20.0 290
142.7 27.0 310
219.8 47.0 350
316.2 72.0 400
439.1 108.0 480
K L
VS
(m /h) (m /h) (mm)
3 3
64.5 12.5 230
109.5 20.0 290
142.7 27.0 310
219.8 47.0 350
316.2 72.0 400
439.1 108.0 480
Reflex Exvoid/Exdirt V — 06.2017
Ø H
(mm) (mm)
206 567
206 616
206 666
206 716
354 966
354 1016
Ø H
(mm) (mm)
206 671
206 719
206 770
206 820
354 1070
354 1120
