2

Description of the device

Note!
In general standard separators are used for flow velocities up to 1.5 m/s.
2.1 Exdirt V
The separator Exdirt V is a dirt and sludge separator for vertical installation that removes circulating free dirt and sludge particles from
closed, liquid-filled plant systems.
Exdirt V DN 50 - 65
1 Desludging valve
• Optional Exferro magnet insert in immersion sleeve (not supplied)
2 Drain valve (included in the accessory kit)
Exdirt V DN 80 - 150
