Teileliste - CARDIOSTRONG CST-TX50-2 Montage- Und Bedienungsanleitung

8.2

Teileliste

Nr. Anz. Hrst. Teilenummer
(01) 1 8000001750
(02) 4 342008003002001
(03) 4 342008003002501
(04) 1 341305202202001
(05) 2 331808205602301
(06) 1 312TA2150011004
(07) 2 592400000000001
(08) 3 362710002501000
(09) 1 8000001751
(10) 2 341306402601001
(11) 2 351706403001101
(12) 2 325214008001003
(13) 2 331808205603601
(14) 1 8000001761
(15) 6 205112081806001
(16) 1 8000001762
(17) 2 331410002003301
(18) 1 8000001752
(19) 1 8000001753
(20) 1 8000001754
(21) 1 8000001755
(22) 1 311TA1150050003
(23) 2 311TA1150060003
(24) 4 204TA1150070000
(25) 4 551040460120110
(26) 1 405114170310005
(27) 4 591405180028012
(28) 1 311TA1150070003
(29) 1 405114170310004
(30) 2 753049030405003
(31) 2 326213006002003
(32) 1 8000001763
Bezeichnung (ENG)
Main frame set
Rubber cushion
Rubber cushion
Space pad
Wheel
Incline lower cover
Power cord buckle
Separate cover
Frame base set
Space pad
desk base foot, adjustable
End cap
Wheel
Base incline bracket
Sleeve
Incline base
Pulley
Support post-L
Support post-R
Handlebar-L
Handlebar-R
Quick button bracket-incline
Quick button
heart sensor
Tension spring
cable
Twin adhesive tape
Quick button bracket-speed
cable
Foam
Handrail end cap
User interface frame
