Parameterization and configuration

9.1.6.6 Object 6505h - Warnings

This object is not supported.
By read access the value is always "0".

9.1.6.7 Object 6506h - Supported warnings

This object is not supported.
By read access the value is always "0".

9.1.6.8 Object 6507h - Profile and software version

This object contains in the 1st 16 bits the profile version which is implemented in the
measuring system. It is combined to a revision number and an index.
e.g.:
The 2nd 16 bits contain the software version which is implemented in the measuring
system. Only the last 4 digits are available.
e.g.:
The complete software version is contained in object 100Ah, see page 94.
Unsigned32
Byte 0
7
2

9.1.6.9 Object 6508h - Operating time

This object is not supported.
The operating time function is not used the operating time value is set to the maximum
value (FF FF FF FF h).

9.1.6.10 Object 6509h - Offset value

This object contains the offset value calculated by the preset function. The offset value
is stored and can be read from the measuring system.
 TR-Electronic GmbH 2006, All Rights Reserved
Page 104 of 112
Profile version: 1.40
Binary code: 0000 0001 0100 0000
Hexadecimal: 1
Software version: 5022.01
Binary code: 0010 0010 0000 0001
Hexadecimal: 22
Profile version
Byte 1
0 15 8
to 2 2 to 2
TR - ECE - BA - DGB - 0038 - 05
40
01
Software version
Byte 2 Byte 3
7 0 15
2 to 2 2 to 2
8
