11. Specifications

Avanti RF
Nominal connection width
Hose connection, diameter
Flow rate at Δp = 0,2 bar
Lower/upper admission width
Nominal pressure (PN)
Water temperature
Ambient temperature max.
Overall length
Total height
Minimum distance pipe centre to floor
Minimum distance pipe centre to wall
Operating weight, approx.
PNR ( = production number)
14
13592_EBA BWT Protector BW_331915-7.indd 14 13592_EBA BWT Protector BW_331915-7.indd 14
Type
G DN
E mm
m³/h
µm
bar
°C
°C
A mm
C mm
D mm
mm
kg
G
C
¾"
20
14
3,0
90/110
10
5 - 30
5 - 40
106
280
400
50
1,8
7-810404
A
D
E
1"
25
14
3,5
100
280
400
50
1,7
