Specifications
GB
Protector BW
Nominal connection width
Hose connection, diameter
Flow rate at ∆p = 0,2 bar
Lower/upper admission width
Nominal pressure (PN)
Water temperature
Ambient temperature max.
Overall length
Total height
Minimum distance pipe centre to floor D
Minimum distance pipe centre to wall
Operating weight, approx.
PNR ( = production number)
10
All manuals and user guides at all-guides.com
Typ
G
DN
E
mm
3
m
/h
µm
bar
°C
°C
A
mm
C
mm
mm
mm
kg
G
C
3
/
"
4
20
14
3,0
90 / 110
16
5 - 30
5 - 40
106
280
400
50
1,8
7-810404
A
D
E
1"
25
14
3,5
100
280
400
50
1,7
