A. GENERAL INFORMATION
Read the warning and safety manual first before you read this manual or instal/use this unit.
The images, figures and illustrations mentioned refered to in the text are located on page 2 of this
manual.
B. INSTRUCTIONS
This appliance dehumidifies living room/area and is best placed in a central spot within the room.
Never use in wet environments or outdoors.
Make sure the appliance always is places on a leveled floor and in horizontal position.
1. Before positioning the appliance, always make sure that it has at least a minimum area of free
space to prevent obstruction of the airflow. This is showed in pic 2.
2. Make sure that doors and windows are closed to allow for efficient functioning of the
appliance.
3. Insert the plug into an earthed socket.
4. If the appliance is to be moved, then always make sure to empty the water tank or disconnect
the drain as instructed in this manual.
C. USE
CONTROL PANEL
The appliance control panel is displayed at, pic 3. Before using the control panel check if:
• The water bucket is correctly installed
• That the bucket is not removed during operation
• If a drain is installed, it must be installed according to the "Drainage hose" section.
The lowest ambient working condition: 5°C / 35% relative humidity The highest ambient
working condition: 35°C / 90% relative humidity.
The control panel functions refer to the numbers on pic 3.
ON/OFF
SPEED
OPERATION
HUMIDITY
TIMER
SWING
Switch on/off the power
Press the button to set up the air speed.(1/2/3/AUTO). Long press
for 3sec can clean the P3/P4 notice.
Press the button to set up ECO dehumidifier /purify/ dehumidifier
mode. Long press for 3 sec can turn on the inner dry appoint-
ment.
Press the button to set up humidity ranges of performance.
(CO/40%/45%---80%/CO)
Set turn off time (0h-9h). Long press for 3 sec to turn on/off the
child lock.
Press the button to switch on/off swing performance.
