Levelflex M
Certified 4..20 mA HART
associated
apparatus
Profibus PA
or
Foundation
Fieldbus
Category II 1/2 G or II 2 G
II 1/ 3 D or
II 1/2 G D or II 1/ 3 D or II 2 G D
Type of protection IP 6x and EEx ia IIC T6..T3
Process pressure dependent on the probe
dependent on the probe
Process
temperature
F12 housing
in Zone 1
in Zone 22
Option e.g. HAW 262 Z
HAW 562 Z
Remote display
Service interface
Please observe the following installation instructions:
1.) Install in accordance with the manufacturer's specifications and the valid standards and regulations.
- Do not operate the level sensor outside of the electrical, thermal and mechanical parameters
2.) The intrinsically-safe input power circuit of the Levelflex M is isolated from ground potential and has a dielectric strength of
at least 500 Vrms with respect to it.
3.) The relationship between the permitted ambient temperature for the electronics housing, dependent on the range of
application, and the temperature classes is shown in the tables (Tab. 1 and Tab. 3).
4.) After aligning (rotating) the housing, retighten the fixing screw (see Operating Instructions).
5.) Use connecting cable for continuous duty temperature ≥ Ta + 5 K
6.) Install the device to exclude any mechanical damage or friction during the application. Pay particular attention to flow
conditions and fittings.
6.1 The instrument is designed for operation in zone 22 or zone 1 (housing) and zone 20 or zone 0 (process connection);
Suitability for simultaneous presence of explosion hazardous gas- air and gas-dust mixtures requires a separate enquiry.
Endress+Hauser
Uo ≤ 30 V
Io ≤ 300 mA
Po ≤ 1.0 W
Uo ≤ 17.5 V Uo ≤ 24 V
or
Io ≤ 500 mA Io ≤ 250 mA
Po ≤ 5.5 W Po ≤ 1.2 W
Probe in Zone 0 and housing in Zone 1 or Zone 2 or probe and housing in Zone 1
Probe in Zone 20 and housing in Zone 22
Probe in Zone 20 and housing in Zone 22 or Zone 1, or
Probe in Zone 21 and housing in Zone 1, or
Probe in Zone 0 and housing in Zone 1 or Zone 2 or Zone 22, or
Probe in Zone 1 and housing in Zone 1 or Zone 22
KEMA 04 ATEX 1129 X
-40 °C ≤ Tu ≤ 80 °C
no cover restriction
electronics compartment cover with
inspection glass permitted
intrinsically-safe power
supply and signal circuit
e.g. FHX40 KEMA 02ATEX1203
Commubox FXA 193 with associated ToF
cable
[EEx ia] IIC or [EEx ib] IIC or [EEx ia] IIB or
[EEx ib] IIB
FISCO model or ENTITY
[EEx ia] IIC or [EEx ib] IIC or [EEx ia] IIB or
[EEx ib] IIB
optionally with or without VU 331 display and
operating module
e.g. route armoured hose up to the housing
observe associated Safety Instructions
(XA193F-.)
observe associated Safety Instructions
(XA077D)
XA 266F-A
Observe
special
instructions
