8.3. malfunctions
If malfunctions occur, check whether
→
the device has been installed according to the
instructions,
→
the electrical and fluid connections are correct,
→
the device is not damaged,
→
all screws have been tightened,
→
the voltage and pressure have been switched on,
→
the pipelines are clean.
english
24
9. sparE parTs
Caution!
Risk of injury and/or damage by the use of incorrect
parts!
Incorrect accessories and unsuitable spare parts may
cause injuries and damage the device and the sur-
rounding area.
• Use original accessories and original spare parts from
Bürkert only.
9.1.

Ordering spare parts

Replacement part sets
When ordering replacement part sets, quote the sets
SET1, SET 3 or SET 7 and the identification number of the
device.
• See replacement part sets
part sets
• The identification number of the device can be found
on the rating plate. See also chapter 6.4.Rating plate
description
english
26
All manuals and user guides at all-guides.com
Torque 5 Nm
9.2.Overview of replacement
Valve does not switch
Possible cause:
• Short-circuit or coil interrupted.
• Core or core area dirty.
• Medium pressure outside the permitted pressure range.
Valve does not close
Possible cause:
• Internal space of the valve is dirty.
• Small control bore in the diaphragm blocked.
• Manual emergency actuation (optional).
9.2. Overview of replacement part
sets
Coil set
SET 1
Wearing-parts set
SET 3
Type 5281 EV
english
25 25
Plunger tube set
SET 7
