CARDIO STRONG Ergometer BC60 Bedienungsanleitung Seite 54

Nr. Bezeichnung (ENG)
A61 SCREW M6X25mm
A62 SLIDER STOPPER
A63 STOPPER
A64 WHEEL
A65 BUSH Φ8XΦ13X16.5L
A66 SCREW M8 x 30mm
A67 NYLON NUT M8X7T
A69 SCREW M8 x 12mm
A70 WAVE WASHER Φ17.5XΦ25X0.3T
A71 WASHER Φ17.5XΦ25X0.3T
A72 CLIP Φ17
A73 WAVE WASHER Φ10.2XΦ13X0.3T
A74 BEARING HOUSING
A75 SCREW
A76 SCREW ST3.5X12L
A77 WIRE TRAP
A78 LONGITUDINAL WIRE TRAP
A79 NYLON NUT M8X7T
A80 NYLON NUT M8X7T
A81 SCREW M8X20
A82 SCREW M6*12mm
A83 EVA PAD STICKER
A84 SMALL IRON TUBE
A85 FIXING SHEET
A86 BRACE
A87 SPRING Φ1XΦ8.5X48L
A88 SCREW ST4.2*16mm
A89 SCREW M5*10mm
A90 CABLE 150mm
A91 SCREW M5*8mm
A92 BUSHING
A93 BEARING 6300 2RS
A94 SCREW ST3.5X16mm
54
Anz. Nr. Bezeichnung (ENG)
REAR STABILIZER
2 B
2 B1 END CAP Φ89( L )
2 B2 END CAP Φ89( R )
4 C FRONT STABILIZER
END CAP
4 C1
4 C2 WHEEL
4 C3 SCREW M5*16
2 D CENTRAL SUPPORT TUBE
1 D1 WASHER M8
1 D2 NUT M8
1 E STOP BAR
1 E1 END CAP
1 F CONSOLE
SADDLE
1 G
2 H BACK REST
1 I FRONT HANDLEBAR
1 I1 END CAP
1 J1 SIDE HANDLE BAR ( L )
SENSOR WIRE 550mm
1 J1-1
SIDE HANDLE BAR ( R )
4 J2
2 J2-1 SENSOR WIRE 550mm
6 J3 HANDLE BAR SPONGE
1 J4 HANDLE PLUSE SENSOR Ф23X3TX190L
1 J5 SENSOR HOUSING
1 J6 SCREW ST2.9X20L
1 J7 SPACEN RING
2 J8 END CAP
PEDAL ( R )
2 L1
1 L2 PEDAL ( L )
4 M1 BOTTLE HOLDER
1 M2 WATHER BOTTLE
1 N1 SCREW M8x102LxS20L
6 N2 SPRING WASHER Φ8.5xΦ13.5x2.5T
Anz.
1
1
1
1
2
2
4
1
2
2
1
1
1
1
1
1
4
1
1
1
1
2
2
2
4
2
2
1
1
1
1
2
8
BC60
