Anhang; Packliste Der Hebebühne; Abmessungen - Twin Busch TWS3-19E Handbuch

Anhang

12.1. Packliste der Hebebühne
S/N
1 Low-profile scissor lift
2 Proection cover A
3 Proection cover B
4 Proection cover C
5 Oil hose fixer
6 Expansion bolt
7 Cross socket cap head tapping screw
8 Control cabinet
9 Plastic expansion tube
10 Rubber pad

12.2. Abmessungen

Name
FL-8801
FL-8801-A9
FL-8801-A10
FL-8801-A11
FL-8801-A1-B7
M16*160
ST4.8*34
FL-8802-A10
M10*40
FL-8801-A14
Handbuch Scherenhebebühne TW S3-19E
Drawing#/Size Material# Description Qty Note
Assembly 1 A pack
Q235A 3
Q235A 1
Q235A 1
Zinc-plating 3
Standard 8
A pack
Standard 20
Assembly 1
Standard 20
Rubber 4
Seite | 27
