CARDIOSTRONG EX80 TOUCH Montage- Und Bedienungsanleitung Seite 37

A66 Washer M12
A67 Nut M12
A68 Led Display
A69 Bearing Sleeve
A70 Bush
A71 Bearing 6201Zz
A72 Screw M12 X 73
A73 Washer M12
A74 Nut M12
A75 Oscillating Axle Base ( L )
A76 Oscillating Axke Base ( R )
A77 Handlebar Supporting Cover
A78 Bearing 6004Zz
A79 Bearing 6905Zz
A80 Front Connecting Shaft
A81 Bush
A82 Bush
A83 C Lip
A84 Bearing Sleeve
A85 Screw M12 X 53
A86 Washer M12
A87 Nut M12
A88 Bearing 2203
A89 Washer M10
A90 Nut M10
A91 End Cap
A92 Crank Housing
A93 Screw
A94 Main Chain Cover ( L )
A95 Main Chain Cover ( R )
A96 Small Chain Cover ( L )
A97 Small Chain Cover ( R )
A98 Screw
A99 Screw
B1 Pedal Supporting Tube ( L )
2 B2 Pedal Supporting Tube ( R )
2 B3 Pedal Housing ( L )
2 B4 Pedal Housing ( R )
14 B5 Lower Pedal Supporing Tube
12 B6 Screw M12 X 109
20 B7 Washer M12
4 B8 Nut M12
4 B9 Pedal Bracket ( L )
4 B10 Pedal Bracket ( R )
1 B11 Pedal Rest ( L )
1 B12 Pedal Rest ( R )
2 B13 Front Cover Pedal ( L )
2 B14 Cushion Pad ( L )
2 B15 Pedal ( L )
2 B16 Screw M4 X 15
4 B17 Screw M6 X 10
8 B18 Pedal ( R )
12 B19 Cushion Pad ( R )
12 B20 Front Cover Pedal ( R )
4 B21 Upper Cap For Pedal Supporting
4 B22 Lower Cap For Pedal Supporting
4 B23 Screw
2 B24 Middle Pedal Supporting Rod
2 B25 Nut M8
2 B26 Bush
2 B27 Bearing 6001 Tp
2 B28 C Clip
2 B29 Screw M8 X 40
1 B30 Screw M12 X 133
1 B31 Bush
1 B32 Bearing 6003Zz
1 B33 Bush
6 B34 Screw
8 B35 Pedal Reinforcement Strip
1 B36 Screw
1
2
2
2
2
2
2
1
1
1
1
1
1
1
6
8
1
1
1
2
2
2
2
4
8
4
4
4
2
2
4
2
4
4
8
37
