GF JRG Montageanleitung Seite 2

D
2
1
Aufbau der
Verbindung
1 Gehäuse
2 O-Ring
3 Kunststoff-
Distanzring
4 Edelstahl-Fixierring
5 Kunststoff-Hülse
2
3 4 5
Description
du raccord
1 Corps
2 Joint torique
3 Bague intercalaire
4 Bague de fixation
5 Douille en plastique
Struttura del
raccordo/collegamento
1 Corpo
2 Guarnizione O-ring
3 Anello distanziatore
in plastica
4 Anello di fissaggio
in acciaio inox
5 Manicotto in plastica
Connection structure
1 Body
2 O-Ring
3 Plastic distance ring
4 Stainless steel
fixation ring
5 Plastic sleeve
