GF JRGUMAT 3400 Montage- Und Bedienungsanleitung Seite 50

E
Function
Body in gunmetal
Hot water seat
in gunmetal
B
Valve slide
in gunmetal,
coated
Warm water
Hot water seat
in stainless steel
1
Standard-
temperatur e
25
40
48
55
70
* only available as type 3400
50
Cold water
2
Ranges of
adjustment
°C
20-30
30-45
36-53
45-65
*
60-80
E
Change in the blended water
temperatur e with 1 full key turn
GN ½-1
°C
DN 15-25
ca. 6 K
Allen key
F
Adjusting screw
D
Regulating gate
A
C
Pin in chromium-
GN 1¼-2
DN 32-50 DN 65/80
ca. 4 K ca. 2 K
in brass
in gunmetal
Thermostat
in brass
Blended
water
nickel steel
