GB
C – Remote control unit
C1 – On/off button (C1=B1)
C2 – Blowing mode button (C2=B2)
C3 – Light button (C3=B3)
C4 – Timer button (C4=B4)
C5 – Inner blades oscillation button (C5=B5)
III. PREPARATION FOR USE
Remove all the packing material and take out the appliance. Remove all possible adhesion
foils, stick–on labels or paper from the appliance. Place the appliance on a suitable flat
and dry surface. Leave free space for due ventilation. Vents in the appliance ensure air
circulation during ventilation and they must not be covered or blocked in another way.
Make sure that the power cord is not damaged and that it does not lead any sharp or hot
surfaces. The electric socket must be easily accessible so that the appliance can be easily
disconnected from power supply if danger appears. Plug the power cord connector to
an electric socket. Moderate smoke for a short time does not mean any defect. Now the
appliance is ready for operation.
To fill water, take out the water tank and pour clear water inside, at the level between MIN
and MAX marks. You can also use upper container A17. For the maximum cooling effect
we recommend using cold water. For the best results use cooling boxes D inserted in the
tank (A5 or A17), after having been sufficiently cooled down in your freezer. You may also
add ice cubes in the water. This will help keeping the water in the tank cold for a longer
time.
INSTALLATION OF WHEELS
The product includes 4 wheels A4 and a tightening spanner E to fix the wheels to the
cooler body A. Please proceed according to Fig. 3. Two wheels have arresting locks
(wheels A, Fig. 3) used to secure the appliance against unwanted move. For a better
stability, we recommend installing the wheels in a cross shape according to Fig. 3.
Cooling boxes preparation
Cooling boxes are delivered filled with powdery material. It is necessary to fill the box with
watter (preferably by distilled water, if need be boiled water) up to the water mark placed
on the box. Afterwards, screw in the box properly.
IV. INSTRUCTIONS FOR USE
Once connected to the mains, the appliance will switch to standby mode. „
display at the same time. To start the appliance, press the switch on/off button B1 – air
blowing will be activated in the normal mode at the medium speed, and the respective
icons will appear on the display. Now you can change the mode and functions by the
respective buttons – see below. To terminate any function and to switch off the appliance,
press repeatedly press the switch on/off button B1.
(ETA356800110)
24 / 54
C6 – Blowing speed setup button (C6=B6)
C7 – Cooling button (C7=B7)
D – Cooling box (200 ml)
E – Tightening spanner
" symbol will
