If impurities are sucked and settle inside the appliance, clean it (see article V. MAINTENANCE).
– When handling the appliance, avoid causing any injury.
– Do not place any device with open flame in the air flow coming out from the appliance
because of danger of burning process interruption.
– Never expose yourself (or animals) to the air flow for an extended period of time.
It may cause health problems.
– Only use original components designed for this type.
– Holes for air ventilation must not be covered.

POWER CORD:

Never use the appliance if the power cord or power plug are
damaged, if the appliance is not correctly operating or if it has
fallen on the floor and been damaged, or if it has fallen into water.
In such cases take the appliance to a professional service centre to
verify its safety and correct function.
If the power cord of the appliance is corrupted, it has to be replaced
by the manufacturer, its service technician or a similarly qualified
person so as to prevent dangerous situations.
– Never put the power cord on hot surfaces and never let it hang over table edge or worktop
edge. If the cord is caught or pulled, e.g. by children, the appliance may overturn and fall
down, causing a serious injury!
– The power cord must not be damaged with sharp or hot objects, open fire, it must not be
sunk into water or bent over sharp edges.
– If you need to use an extension cord for justified reasons, it must be undamaged and
comply with the applicable standards.
II. DESCRIPTION OF THE APPLIANCE (Fig. 1)
A – Cooler body
A1 – Outer moving blades (fixed)
A2 – Inner moving blades (automatic)
A3 – Watermark
A4 – Wheels
(item No. ETA356800030)
A5 – Water tank
(item No. ETA356800040)
A6 – Groove of running water
A7 – Down-flowing water hole
A8 – Pump
(item No. ETA356800050)
A9 – Pump arresting locks
A10 – Cooling pad
A11 – Pad cover
A12 – Water discharge holes
A13 – Arresting lock cover
A14 – Cover fixing screws
A15 – Power cable
A16 – tank cover
A17 – upper water tank
(item No. ETA356800060)
B – Control panel
B1 – On/off button
B2 – Blowing mode button
B3 – backlit button
B4 – Timer button
B5 – Inner blades oscillation button
B6 – Blowing speed setup button
B7 – Cooling button
B8 – remote control signal receiver
B9 – Blowing speed setting icon
B10 – Activated cooling icon
B11 – Activated blades oscillation icon
B12 – Timer icons
B13 – On/off icon
B14 – Normal mode icon
B15 – Natural mode icon
B16 – Sleep mode icon
