7. Maintenance and cleaning
7
Fig. 1 - Fitting the sealing rings, sealing discs and O-rings
Retaining ring
1
Sealing disc, PVC, ⅛"
2
Brass sealing disc, PVC, ⅛"
3
Flat head screws M3 x 6
4
Quadring
5
O-ring 3.17 x 1.78
6
O-ring 9 x 3
7
WIKA operating instructions, model CPP30
6
6
1
2
3
4
5
