Intended use

2 Intended use
WARNING
!
Danger of explosion!
The Dräger REGARD 3900 Modbus Gateway V2.0 is not designed or authorised for
use in areas where flammable or explosive gas mixtures could develop.
The REGARD 3900 Modbus Gateway V2.0 is needed for the communication between the con-
trol unit REGARD 3900/3910 and the visualisation panel RVP 3900.
The visualisation panel receives data from up to 8 control units and displays them in a graphical
form. Every system needs its own REGARD 3900 Gateway. The gateway transforms the CAN
bus data from the REGARD 3900/3910 in to the Modbus protocol. This Modbus data is needed
for the visualisation of the REGARD 3900 System.
Before using the REGARD 3900 Modbus Gateway V2.0 it has to be addressed.
The addressing is carried out via DIP-Switches on the front side of the gateway.
Example:
REGARD 3900/3910
System
1
2
3
4
5
6
7
8
9
10
Are there more than 1 REGARD 3900/3910 systems to connect to a RVP 3900 the termination
resistors of the last in line connected REGARD 3900 Modbus Gateway V2.0 have to be set via
the DIP-Switches A and B.
16
Gateway Address Modbus
Address
1
2
3
4
5
6
7
8
9
10
Dräger REGARD 3900 Modbus Gateway V2.0
RVP3900
Max. 8 Controller
1
2
3
4
5
6
7
8
Not possible!
Not possible!
