Digital ADAS CPU configuration via
scantool
1 Take the scantool
2 Open the Digital ADAS Settings menu
page on the scantool
3 Press the button indicated in the
image when prompted
4 Set some parameters:
a. Test Type = Axis of symmetry (set
by default), allows you to perform
the calibration using the clips on
the front wheels. (Note: It is pos-
sible to select Direction axis only if
you want to carry out the calibra-
tion according to the requirements
of the French CESVI, using the
clips on the rear wheels)
b. TV model = 2
c. Laser model = 1
d. Strip model = 2
e. Radar target model = 3
f. Remote control model = 1
The software is displayed on the
5
digital target and the system is ready
to work. The configuration is finished.
The presence of the triangle in the
center of the digital target indicates
what was written before. The triangle
also indicates the center of the digital
target
The numbers to be reported in the
settings are placed with adhesive
on the back of each component.
The vertical remote control setting
is visual, depending on the remote
control in your possession.
