Description Of The Equipment; Main Components; Intended Use - MAHLE TechPRO Digital ADAS Installationsanleitung

12
Digital ADAS
Installation manual

5. Description of the equipment

5.1

Main components

Main components
a Mobile support structure
65" Digital Target
b
c Laser rangefinder
Mirror for laser calibration
d
e Metric bar
f Digital ADAS CPU with keyboard
g Structure vertical movement remote
control
f
g
5.2

Intended use

The equipment covered by this manual has
been designed for a simple and reliable
calibration of driver assistance systems, such
as cameras and radar. Digital ADAS must be
used in conjunction with a scantool produced by
MAHLE Aftermarket Italy S.p.A. (see manual of
the scantool instrument).
b
d
c e
a
c
