Warenannahme und Produktidentifikation
20
A
B
 7 Typenschilder des NRR261 für FM
A Typenschild des NRR261 für FM (integrierter NAR300)
B Typenschild des NRR261 für FM (separater NAR300)
1 Bestellcode (Order code)
2 Seriennummer
3 Versorgungsspannung
4 Herstellungsdatum
