Dati Parametrici - Balluff BMP 01 P A P-Serie Betriebsanleitung

BMP 01- _P _ _ _ _ _A- _ _ _ _ - _ _ -P _ _ /P _ _ -S4/P _ _ -S75
Sensore di posizionamento lineare a campo magnetico
8
Interfaccia IO-Link (seguito)
8.5

Dati parametrici

Indice Subindice
MDC (Measurement Data Channel) (vedere capitolo 8.5.1)
0x00C1 (193) 0
0x00C2 (194) 0
0x00C3 (195) 0
0x00C4 (196) 0
0x4080 (16512) 0, 1, 2, 3, 4
0x0202 (514) 0, 1, 2
Frontend settings (vedere capitolo 8.5.2)
0x02FA (762) 0
0x00BD (189) 0
SSC (Switching Signal Channels) (vedere capitolo 8.5.3)
0x003A (58) 0
0x003B (59) 0
0x003C (60) 0, 1, 2
0x003D (61) 0, 1, 2, 3
0x003E (62) 0, 1, 2
0x003F (63) 0, 1, 2, 3
0x4000 (16384) 0, 1, 2
0x4001 (16385) 0, 1, 2, 3
0x4002 (16386) 0, 1, 2
0x4003 (16387) 0, 1, 2, 3
Device Configuration
0x00B4 (180) 0, 1, 2
0x00F8 (248) 0, 1, 2
Condition Monitoring
0x0052 (82) 0, 1, 2, 3, 4, 5 Device Temperature (vedere capitolo 8.5.6)
0x0053 (83) 0, 1, 2
0x0057 (87) 0, 1, 2, 3
0x0058 (88) 0
Parametri di sistema
0x0003 (3) 0, 1, 2, 3, 4, 5 Data Storage (vedere capitolo 8.5.10)
0x000C (12) 0
0x000D (13) 0, 1, 2, 3, 4
0x000E (14) 0, 1, 2, 3
Tab. 8-6: Dati parametrici interfaccia IO-Link
