GB
Notice:
In the future use of refrigerator, doors uneven phenomenon may occur to the weight of
stored food. Then please adjust according to the above methods.
3. The stability can be checked by alternately bump-
ing on the diagonals. The slightly swaying should be
the same in both directions. Otherwise the frame can
warp; possible leaking door seals are the result. A low
tendency to the rear facilitates the closing of the doors.
Fine tuning of the doors
If the doors are not in one level, this mismatch can be
remedied by following:
Using adjustable foot/adjustable hinge
Rotate the adjustable foot or adjustable hinge ac-
cording to the direction of arrow to turn up or down
the foot. Adjustable hinges can be fine tuned with a
6mm Allen wrench.
Contact after-sale service if needed.
Installation
41
