6) To activate and deactivate a submenu while replay-
GB
ing, press the button MENU (7). This submenu
allows you to change the repeat function (Voice
Repeat: No / One / All One / All, see chapter 6.1,
submenu "Play Setup").
7) To stop the replay, press the button STOP/ ESC (5);
the list of audio recordings will reappear. To return
to the basic menu, press the button STOP/ ESC
twice.
9.3 Managing audio recordings
The audio recordings are managed in the same way as
the video recordings, see chapter 8.2.
10 Functional Group PHOTO
Taking, viewing, managing snapshots
10.1 Taking snapshots
1) If the basic menu (fig. 2) fails to appear on the dis-
play, press the button STOP/ ESC (5) [repeatedly].
2) Select PHOTO with the button
press the orange button REC/ PAUSE (6) or the but-
ton
on the remote control (22). The display will
show the image presently taken by the camera.
"Preview" will be inserted on the display for infor-
mation.
3) To take a snapshot, press the button REC/PAUSE
or the button
"snap shot" for information.
4) To take a series of snapshots where the next snap-
shot is automatically taken after an interval to be
defined, proceed as follows:
a) Press the button MENU (7) during the preview.
The submenu "Snap Shot Time" will appear.
b) Press the button
with the button
Off /10 / 20 / 30 / 60 Sec
(setting "Off" = no series of snapshots)
c) Confirm the setting selected with the button
The submenu will disappear and the camera will
start taking the series of snapshots.
5) To stop the preview or the series of snapshots,
press the button STOP/ ESC (5) or the button
the remote control. The display will show the snap-
shots as thumbnail images or as a file list
(adjustable under SETTING → Play Setup → Photo
Thumbnail View: YES / NO).
The last snapshot taken is selected. Press the
button
to view it. With the function "Slide Show"
activated, all snapshots will be shown successively
(SETTING → Play Setup → Slide Show). To stop
this view, press the button STOP/ ESC. To return to
the basic menu, press the button STOP/ ESC twice.
18
or
. The display will briefly show
(13) and select the interval
or
:
10.2 Viewing snapshots
1) The list of thumbnail images or of snapshot files
must appear on the display. If it fails to appear,
press the button STOP/ ESC (5) repeatedly until the
basic menu (fig. 2) is shown. Select PHOTO with
the button
(13).
2) The display will show the snapshots as thumbnail
images or as a file list (adjustable under SETTING
→ Play Setup → Photo Thumbnail View: YES/ NO).
The file names created by the recorder are coded
as follows:
3) Select the desired snapshot from the list with the
button
(13).
4) To activate and deactivate a submenu while viewing
a snapshot, press the button MENU (7).
(12) and
Sub Menu
Slide Show
Slide Show Time dwell time of a snapshot
Select the menu lines with the button
change a setting, press the button
the setting with the button
setting, press the button
appear.
5) To stop the view of snapshots, press the button
STOP / ESC. The list of snapshots will reappear. To
return to the basic menu, press the button STOP/
ESC twice.
Note: Snapshots will not be displayed on a monitor con-
nected to the jack A / V OUT (19).
10.3 Managing snapshots
The snapshots are managed in the same way as the
video recordings, see chapter 8.2.
.
11 Further Possibilities
on
11.1 Button lock feature
To protect the buttons against any accidental actua-
tion, set the sliding switch (4) of the lock to the left posi-
tion. The padlock icon (e) indicates activation of the
button lock feature. When you press a button, a large
padlock icon will briefly appear.
The remote control (22) has a separate button lock.
To activate it, push the sliding switch HOLD on the side
of the remote control in arrow direction; the buttons will
be locked mechanically.
or
(12) and press the button
or
(12) and press the button
show snapshots one after another
or
; the submenu will dis-
or
. To
and make
. To confirm the
