11.2 Reset

In case of malfunction during operation, a reset is pos-
sible: Press the button RESET (15) on the lower edge
of the recorder by means of a thin object. The display
will be extinguished and the recorder will be restarted.

11.3 Copying recordings onto a computer

For data backup or for making space on the recorder
for new recordings, you will be able to copy the files of
the recordings onto a computer.
1) Remove the cover on the right side of the recorder
and connect the USB port (10) via the USB cable
provided to a USB port on the computer.
2) Switch on the recorder. In case of correct connec-
tion, the display will show "USB Connected".
3) Video recordings can be found in the folder VIDEO,
audio recordings in the folder VOICE and snap-
shots in the folder PHOTO. From these folders, the
files can be copied onto the computer and back
from the computer into the corresponding folders
for replay.

11.4 Wrist strap

To carry the recorder on your wrist, lead the wrist strap
through the lug (1), then pull the other end through the
loop to fasten it.
All rights reserved by MONACOR
be reproduced in any form or by any means for any commercial use.
INTERNATIONAL GmbH & Co. KG. No part of this instruction manual may
®

12 Specifications

Recorder
Max. resolution: . . . . . . . 720 × 576 pixels
Max. frame rate: . . . . . . 25 fps
Video compression: . . . H.264
Internal memory: . . . . . . 1 GB
Display: . . . . . . . . . . . . . colour LCD
Resolution: . . . . . . . . 320 × 240 pixels
Diagonal screen size: 6 cm (2.4")
Power supply: . . . . . . . . via rechargeable lithium ion
Ambient temperature: . . 0 – 40 °C
Dimensions: . . . . . . . . . 95 × 20 × 60 mm
Weight: . . . . . . . . . . . . . 105 g
Other features: . . . . . . . integrated microphone and
Camera
Image sensor: . . . . . . . . CCD chip, 8.5 mm (
Number of pixels: . . . . . hor. 768 × vert. 582
Resolution: . . . . . . . . . . 450 lines
Colour system. . . . . . . . PAL
Lens: . . . . . . . . . . . . . . . 3.7 mm/ 1: 2.0
Minimum illumination: . . 0.1 lx
Power supply: . . . . . . . . 5 V /200 mA via the
Ambient temperature: . . 0 – 40 °C
Dimensions: . . . . . . . . . 30 × 20 × 28 mm
Weight: . . . . . . . . . . . . . 22 g
Automatic functions: . . . white balance,
Subject to technical modification.
battery (3.7 V, 2000 mAh) or
5 V via power supply unit
provided and connected to
230 V~ / 50 Hz
speaker
1
⁄ ")
3
recorder
electronic shutter
GB
19
