Remove the cover on the right side of the recorder,
GB
then push the card with its contacts showing
upwards into the slot (9) until it engages. To remove
the card, slightly push it in until it disengages.
Important! To prevent data loss, always make sure
that the recorder has been switched off when you
insert or remove the memory card.
When the basic menu (fig. 2) is displayed and you
keep the button MENU (7) pressed for 3 seconds,
the recorder will switch between the internal mem-
ory and the memory card [SD icon (d) inserted]. For
further settings, select SETTING and activate the
menu "Memory Setup" (chapter 6).
5) Connect the power supply unit (23) provided to
the jack DC 5 V (16) and to a socket (230 V~/ 50 Hz).
When the power supply unit has been con-
nected, the integrated battery will be recharged.
Charging time of a discharged battery
Recorder switched on
Recorder switched off
Operating time of a fully charged battery
Recording mode
Replay mode
The battery is fully charged when all three seg-
ments of the battery status indication (h) are dis-
played and the left segment stops flashing. Always
fully charge the battery prior to initial operation
and mobile applications.
If the recorder is not in use for a longer period of
time, disconnect the power supply unit from the
mains socket; even with the recorder switched off, it
has a low power consumption.
5 Switching On / Off,
Overview of Functions
To switch on, keep the button
the display (14) lights up. After loading the operating
system, the basic menu (fig 2) will appear and the
upper line will show the following information:
a date
b time
c clock icon when a time-controlled recording has
been programmed
d SD icon when a memory card has been inserted
and selected
e padlock icon with activated button lock feature
f speaker icon; crossed out when the sound has
been deactivated
g value of the volume adjusted
h battery status indication
= battery discharged
To switch off, keep the button
play shows POWER OFF.
Five functional groups are available for operation of
the recorder:
14
5 h approx.
3.5 h approx.
2.5 h approx.
4 h approx.
(13) pressed until
= battery fully charged,
pressed until the dis-
RECORD
– live surveillance
– preview of a recording
– audio and video recordings
VIDEO
– audio and video recordings
– replaying recordings
– managing recordings
VOICE
– audio recording via the internal microphone or the
camera microphone
– replaying audio recordings
– managing audio recordings
– preview of snapshots
– taking individual snapshots or a series of snapshots
– viewing snapshots
– managing snapshots
SETTING
– making settings
To match the recorder optimally to its range of applica-
tion, make all the required settings via the functional
group SETTING first.
6 Functional group SETTING
Making settings
1) If the basic menu (fig. 2) fails to appear on the dis-
play, press the button STOP/ ESC (5) [repeatedly].
2) Select SETTING with the button
press the button
appear:
Main Menu
Record Setup
Timer Record Setup
Play Setup
Display Setup
Memory Setup
System Setup
3) Press the buttons
ual menu lines and the button
the corresponding submenu. When you press the
button STOP/ESC, you will return to the previous
menu level; when you press the button MENU (7),
you will always return to the basic menu.
4) To make a setting in a submenu, select the corre-
sponding menu line and press the button
Press the button
confirm with the button
or
(13). The main menu will
and to select the individ-
(13) to activate
or to make the setting and
.
and
.
