˜ Description of parts
Before reading, unfold the page containing
the illustrations and familiarise yourself with all
functions of the product .
Figure A:
Blow connector with notch
[ 1 ]
Power cord holder
2 ] [
Latch
[ 3 ]
Vacuum connector with notch
4 ] [
Metal container
5 ] [
Straight nozzle
6 ] [
Crevice nozzle
[ 7 ]
Swivel caster
8 ] [
Hose
9 ] [
Hose coupler
[ 10 ]
Hose adaptor
[ 11 ]
(outer Ø: 41 mm; inner Ø: 38 mm)
(Coupler marking)
12 ] [
Carry handle
13 ] [
Container lid
[ 14 ]
Filter cleaning switch
[ 15 ]
Figure B:
Indicator bar
[ 16 ]
On/off switch
[ 17 ]
Power cord with power plug
18 ] [
(power plug not illustrated)
Nozzle holder
[ 19 ]
Figures C, G:
Centre marking
[ 20 ]
Pleated filter
21 ] [
Wire mesh
22 ] [
Safety switch
[ 23 ]
Filter thread
24 ] [
8 GB
˜ Technical data
Ash vacuum : PAS 1200 F5
Model number
with VDE plug : HG08002
with BS plug : HG08002-BS
Rated input
power (power
consumption) : 1200 W
Rated input
voltage : 220–240 V∼, 50 Hz
Suction force : 16 .5 kPa (165 mbar)
Suction rate : 25 l/s
Power cord length : 5 m
Protection class
: II /
Hose length : approx . 1 .5 m
Filter type : Class M
Metal container capacity
Size : Ø 30 .5 cm x H 35 cm
Net volume : 14 l
˜ Safety features
The safety switch
23 ] [
from being operated when the pleated
filter is not installed .
[ 21 ]
prevents the product
