B. Ambient sensing thermostat (not recommended for AT-TS-14)
EN
Select a suitable place for installation of the thermostat and the sensor for ambient
DE
temperature measurement.
In case of outdoor installation of the thermostat, the sensor cable can be made shorter so
FR
that the sensor is located within the screwed gland (M16).
Make sure NOT to mount the sensor tip in direct sunlight or wind exposure; a sun and rain
cover is recommended.
Do not install the thermostat under the insulation.

Technical data:

Adjustabletemperaturerange
Supplyvoltage
Powerconsumption
Max.switchingcurrent
Max.conductorsize
Switchingdifferential
Switchingaccuracy
Switchtype*
*The switching relay is potential-free when the bridge wire is removed between terminals 1 and 5.
Enclosure:
Temperaturesetting
Exposuretemperature
Ingressprotection
Entries
Weight(withoutsensor)
Material
Lidfixing
Mounting
|
4 nVent.com/RAYCHEM
AT-TS-13
–5to+15°C
230V+10%/–15%,50/60Hz
max.1.8VA
16A,250VAC
2.5mm
2
0.6–1K
+5°C:±1K(calibrationpoint)
SPST(normallyopen)
inside
–20°Cto+50°C
IP65accordingtoEN60529
M20forsupplycable(dia.8-13mm),M25forconnectionto
heatingcable(dia.11-17mmnotdirect)andM16forsensorcable.
±440g
ABS
Nickelplatedquickreleasescrews(4)
nVentRAYCHEMpipesupportbracketJB-SB-01,SB-110orSB-111
orwallmounting
AT-TS-14
0°Cto+120°C
