Technical Data - nVent RAYCHEM HWAT-ECO V5 Installationshinweise

3.2 Technical data
Product specification
EN
DE
Supply voltage
DK
Power consumption
Power output relay
CZ
(heating cable)
FR
Power supply terminals
Heating cable terminals
IT
Alarm terminals
NL
Sensor terminal - Boiler
PL
Sensor terminal - Pipe
ZH
Alarm relay
Circuit breaker
Real time clock
Clock backup
Clock accuracy
Settings
Operating temperature
Selectable temperature
Pre-programmes
Material
Dimensions
Ingress protection class
Weight
Mounting
Entries
Storage temperature
Flammability class
Temperature sensor type
Sensor tip dimensions
Sensor cable length
Temperature range
Sensor data
|
10 nVent.com/RAYCHEM
HWAT-R/-M/-L heating cables only
Electrical properties
180-253 VAC, 50/60 Hz
3,5 VA max
20 A / 230 VAC
3 x 6 mm² max
3 x 6 mm² max
3 x 1,5 mm² max
2 x 1,5 mm² max
2 x 1,5 mm² max
Single pole double throw relay, volt-free,
Max. switching capacity (resistive load only)
1 A/30 VDC 0.5 A/125 VAC,
Max.: 60 VDC/125 VAC
Max. C 20 A (C-Characteristic)
Automatic Summer/Winter time and
Leap year correction
10 days
A variation of ± 10 minutes per year is possible
All settings are stored in non-volatile memory
0°C to 40°C ambient
37°C up to 65°C in 24 blocks per day
7 built-in building specific programmes, can
be edited
Enclosure
Polycarbonate
210 mm x 110 mm x 85 mm
IP 54
990 g
DIN-Rail mountable 35 mm
2 x M25 and 2 x M20
–20°C to +50°C
D category (DIN EN 60730/VDE 0631-1)
Sensor
Standard NTC 2,0 KOHM at 25°C, 2 wires
Ø 5 mm; length 20 mm
3 m; extendable up to 100 m , 2 x 1,5 mm²
0°C to 90°C
40°C
45°C
50°C
55°C
60°C
65°C
1211 Ω
1033 Ω
884 Ω
762 Ω
658 Ω
571 Ω
