Or, you can simply insert the seat into the rails from the front before the running rails
are strictly fixed, so that you don't have to remove the limiters.
Step 5
Remove the track limiters from the rear rails.
Then insert the seat into the rails. Make sure
that the notch on the seat points backwards.
Then reattach the two track limiters again.
Step 6
Push the two frame halves together. Place
the footplate on the metal bracket. Fasten
the footplate in the middle of the front frame
with four M8x45 screws and washers (15) &
(18). Now attach the base plate to the top of
the tank unit with two M8x35 screws and
washers (14) & (18) and four additional
screws M8x45 screws and washers (15) &
(18) through the side rails.
Then screw the four M8x20 screws (13)
from the rear through the metal bracket into
the footplate.
Step 7
Mount the display (2) with four screws (19)
on top of the tank unit (1). Then connect the
data cable with a plug.
Step 8
Hook the retraction elastic into the eyelet on
the lower rear end of the frame.
