steute RF Rx SW868-4S Montage- Und Anschlussanleitung Seite 5

RF Rx SW868/SW915/SW917/SW922-4S
//
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur sans fil
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor sem fio
English
Operation mode LED 1 LED MD
Standard flashes flashes
fast fast
Relay functions
Standard, flashes on
inverse output fast
Relay energised on flashes
fast
Relay energised, on on
inverse output
Transmitter functions
Logic function flashes on
slowly
Latching on flashes
function slowly
Wiping flashes flashes
function slowly slowly
Additional functions
Battery off flashes
monitoring (LED 3 slowly
flashes)
Status off flashes
monitoring (LED 4 slowly
flashes)
Notice
If only one or both additional functions are activated, no further trans-
mitter can be taught in.
Operation mode logic function
- Select logic function. -> LED MD flashes fast.
- Set logic function push-button S2. -> Observe LED display (see table).
- When the desired LED combination is displayed, press push-button
S1 for 1 s.
Logic LED 1 LED 2
function
OR on -
AND - on
XOR - -
Function
Relay energised by actua-
tion, relay and transmitter
functions are reset.
Relay de-energised by actu-
ation, inverse output signal.
Relay energised by providing
operating voltage.
Relay energised by providing
operating voltage, inverse
output signal.
The logic functions OR, AND
or Xor are selectable.
Latching function/
Impulse function
Wiping function, contact
automatically de-energises
after the set time.
Relay K3 indicates under-
voltage of the taught-in
and battery-powered
transmitters.
Relay K4 indicates status
error; activates function only
in combination »transmitter
with status signal«.
LED 3 LED 4 LED MD
- - flashing
- - flashing
on - flashing
Operation mode wiping contact
- Select wiping function -> LED MD flashes fast.
- Set the time of the wiping contact. The pre-set time can be changed
with push-button S2. -> Observe LED display (see table).
- During mode »wiping time flexible«, count the pulses of the flashing
LED 4 and confirm the time achievement (1 s/pulse) with push-
button S1.
- In order to change set time of the wiping contact, start selection of
operation mode and select wiping function again.
Time of wip- LED 1
ing contact
500 ms -
1 s on
2 s -
5 s -
flexible -
Operation mode status monitoring
- After selection of status monitoring the LED MD flashes
every second.
- The LEDs 1 - 4 indicate the adjustable status times.
- The display of the LED changes every 5 s (see table).
- When the required LED combination is indicated, press the push-
button LRN for 1 s. The desired operation mode is now activated.
- Without confirmation of the selection, the default value of 10 s will
be set.
Status signal LED 1
time
10 s on
100 s on
1 000 s on
10 000 s on
Function: If no status information is given by the taught-in transmit-
ters, relay K4 automatically triggers the alarm after the status time
has elapsed 2.2 times.
Attention! Please ensure that the taught-in transmitter is set to the
correct status signal time.
Teaching in of transmitters
The output of the receiver can be switched by a maximum of 40 trans-
mitters. To do this, teach in each transmitter once in the receiver.
- Press push-button LRN approx. 1 s -> LED MD flashes slowly (2 Hz).
- Channel selection: press push-button SEL.
- Actuate transmitter to be taught in -> the LED of the corresponding
channel is off for a short time.
- To leave teach-in mode: press push-button LRN approx. 1 s ->
LED MD lights up.
5 / 24
LED 2 LED 3 LED 4
- - -
- - -
on - -
- on -
- - flashing
LED 2 LED 3 LED 4
- - -
on - -
on on -
on on on
LED MD
flashing
flashing
flashing
flashing
-
LED MD
flashing
flashing
flashing
flashing
