Fault messages of the robot lawn mower in the LCD display (50)
Fault
Rolling over
Wheel slip
STOP button error
PCB overtemp.
Rain
Sensor fault
Anl_FREELEXO_SMART_SPK13.indb 51
Anl_FREELEXO_SMART_SPK13.indb 51
GB
Possible cause
- The robot lawn mower was
constantly tilted for 10 se-
conds
- The robot lawn mower has
been tilted for a prolonged
time in one direction
- The rear wheels (8) have
lifted due to an obstacle
- The rear wheels (8) can ro-
tate freely due to an uneven
lawn
The display cover (23) is open
but the STOP button (3) was
not pressed
The temperature of the rechar-
geable battery is too high/low
or the controller is overheated
- If the battery temperature
exceeds 65°C, the robot
lawn mower will return to the
charging station (19).
- If the battery temperature ex-
ceeds 45°C or drops below
0°C, charging will be stopped
and the robot lawn mower
will wait at the charging stati-
on (19).
- The rain sensor (5) has trip-
ped.
- The robot lawn mower was
stopped due to a sensor er-
ror
- 51 -
Remedy
Press the STOP button (3) to open the dis-
play cover (23). Restart the mowing operati-
on via the control panel (2):
- Move the robot lawn mower to a level area
and restart it.
- If the robot lawn mower has tilted because
of a steep slope in the mowing area, ad-
just the perimeter wire (18) accordingly to
avoid severe inclines.
Press the STOP button (3) to open the dis-
play cover (23). Restart the mowing operati-
on via the control panel (2):
- Move the robot lawn mower to a level area
and restart
Press the STOP button (3) to open the dis-
play cover (23). Restart the mowing operati-
on via the control panel (2):
- Check whether the display cover (23)
can be opened and closed freely with the
STOP button (3).
- Check whether the STOP button (3) func-
tions correctly.
- Set the work time in summer to the early
hours of morning and avoid running the
robot lawn mower during the hours of the
day when it is hot.
- After the rechargeable battery or control-
ler has cooled down to the permissible
temperature range, the robot lawn mower
will automatically return to the program-
med operating mode
- Wait until the robot lawn mower has dried
out.
- A detailed description of the sensor can
be found in section 5.2.
Switch off the main switch (7) (OFF) and
then switch it back on (ON) again to restart
the robot lawn mower.
