DEMOUNTING WHEELS
FOR EARTHMOVING
MACHINES AND WITH
A SIDE RING
with the rim.
Keeping the tyre rotating, press with
the bead breaker disc on the front bead
(Fig. 34) until freeing the lock ring that
Fig. 35).
Repeat the bead breaking operation on
the rear side as shown in Fig. 36 and
continue until the tyre comes out, with
or without the side ring.
N.B. For wheels that are particularly hard
and locked on the side ring, demount
the tyre with the side ring still attached.
36) like a normal rim and break it from
the rear.
For a good bead breaking result, both in
the front as well as in the rear, insert
the bead breaker plate between the rim
edge and the bead until just touching
the shoulder of the rim.
MOUNTING WHEELS
FOR EARTHMOVING
MACHINES AND WITH
A SIDE RING
76
Fig. 34
Fig. 35
A
Fig. 36
-
A
Fig. 37
