Kemper KHS Mini-Systemsteuerung MASTER 2.1 Montage- Und Bedienungsanleitung Seite 166

EN
6.6
Logbook and flushing protocol
3
Ill.: 6.6.5: Opening the CSV log file dialogue
The KHS Mini Control System have a facility to
be used as measuring instruments. To do this, the
Control System that are connected to a sensor, as
described in Chapter 6.3, are configured. Use the
„Datalogging" function to generate, delete and
save the recorded measurement data records in the
form of a CSV file on the PC. Up to 12 million
166/265 – K410068602008-00 / 01.2023 – © www.kemper-group.com
Data transfer
These buttons can be used to open and save either
the logbook or the flushing log. The logbook (event
log) documents the water exchange procedures,
error messages and parameter changes perfor-
med by the KHS mini system control. The flushing
log documents all the measuring and flushing
parameters.
4
lines can be backed up. Click the
button to generate the current CSV file, which is
not yet completely full. Click the CSV file to open
a dialogue as shown in Fig. 6.6.6. Here you can
select whether the flushing log should be saved or
immediately opened. Use the
query as shown in Fig. 6.6.7. Click OK to delete the
selected file.
CREATE LOGFILE
button to open a
